MODEL LCD40+3X440R
Dual Run Capacitor 40/3 MFD 370/440V Round
Additional information
| Weight | 0.50 lbs |
|---|---|
| Dimensions | 0.00 × 0.00 × 0.00 in |
Description
40/3 MF / 440 VA
A dual run capacitor rated at 40 + 3 microfarads and 440 volts, designed to support both compressor and fan motors in HVAC systems. Features aluminum oil-filled construction with three terminals labeled C (Common), HERM (compressor), and FAN.
Key Features
- Dual rated 40 + 3 microfarad capacitance values in a single round case
- Rated for 370/440 VAC operation with -40 to 185 degrees F temperature range
- Three terminal design supporting both hermetically sealed compressor and fan motor
- Aluminum oil-filled construction for reliable performance
- 5% tolerance specification
Technical Specifications
| Specification | Value |
|---|---|
| Capacitance | 40 + 3 MFD |
| Voltage | 440/370 VAC |
| Type | Dual Run |
| Shape | Round |
| Application | Motor Run |
Ideal For
- Central air conditioner compressor and fan motor operation
- Heat pump systems requiring dual capacitor support
- Residential split system AC units
- Commercial refrigeration equipment with dual motor loads
