MODEL LCR12.5X440R
Run Capacitor 12.5 MFD 370/440V Round
Additional information
| Weight | 0.50 lbs |
|---|---|
| Dimensions | 0.00 × 0.00 × 0.00 in |
Description
12.5 MF / 440 VA
A 12.5 microfarad, 440 volt AC motor run capacitor designed for HVAC applications. This oval-shaped capacitor is used to provide consistent power to air conditioning compressors, furnace blower motors, and condenser fan motors.
Key Features
- 12.5 MFD capacitance rated for 370/440 VAC dual voltage operation
- Oval aluminum case construction with metallized polypropylene film dielectric
- Operating temperature range of -40°F to 85°F (-40°C to 85°C)
- UL and CUL recognized, RoHS compliant, non-PCB oil filled
- Standard tolerance of +/- 5% for reliable motor performance
Technical Specifications
| Specification | Value |
|---|---|
| Capacitance | 12.5 MFD (microfarads) |
| Voltage | 440 VAC (370/440V compatible) |
| Type | Motor run capacitor |
| Shape | Oval |
| Application | HVAC motors, compressors, blower fans |
Ideal For
- Air conditioning compressor replacement and service
- Furnace blower motor installations
- Condenser fan motor repairs
- Residential and light commercial HVAC equipment
