GE · MODEL AVES09DCXXA
GE Vertical Zoneline V10 Electric Heat 208/230V 9000 BTU Corrosion R454B
RefrigerantR454B
Documents
Additional information
| Brand | GE |
|---|---|
| Refrigerant | R454B |
| Claims & Certifications | California Prop 65, UL, AHRI, CUL, NRCAN |
| Zoneline Features | Corrosion Protection, Fast-Connect Plumbing, Insta – Platform™, Onboard Diagnostics, Quick-Install Plenum, Reverse Cycle Defrost, Saves 60% on Install Time, Self-Contained Drainage System, SmartHQ™ Management Capable (Requires module & Subscription), Ultra-Quiet |
| Control Type | Tactile touch pad with LED Display |
| Refrigerant Charge (oz.) | 32 |
| Sensible Heat Ratio | 0.77 |
| Product Type | Vertical Air Conditioners |
| Refrigerant Type | R454B |
| Makeup Air | No |
| Cool with Resistance Heat | Yes |
| Cooling BTU (230 / 208V) | 8900 / 8800 |
| Volts/Amps | 230 / 208V |
| Accessories Required for Installation | Access panel / Return Air Grille, Insta-Platform™, Outdoor Grille, Power Connection, Thermostat, Wall Plenum |
| Cooling - Amperes | 3.7 / 3.5 |
| Cooling - Watts | 735 / 745 |
| Corrosion Treated | Yes |
| EER2 Minimum (230V) OPT for SEER2 | 12.1 / 12.0 |
| Dehumidification (pts./hr.) | 1.8 |
| Color Appearance | Gray |
Description
Features
Designed & Assembled In America
Date of Manufacture – 2025 or later
Warranty
Warranty Notes: See written warranty for full details
Labor Warranty: Limited 1-year entire appliance
Parts Warranty: Limited 2-year entire appliance
